| Sealed Nickel-Cadmium cylindrical rechargeable battery |
 |
These batteries have features as excellent sealing performance,leakage proof,repeatable pressure vent,high current discharge,1C5A current quick charge,long service life and can be interchanged with dry cell etc. These products can be combined in series to every kind of storage batteries which include each kind of external dimensions and voltage according to user's requirements. These batteries are widely used as DC power sources for communication,lighting,photography,camcorder,police equipments,emergency lights,electronic instruments and apparatus,minicomputers and household electric appliances etc. |
| Models | IEC | Size | Nominal Capacity (mAh) |
Nominal Voltage(V) |
Max Weight (g) |
Max. External Dimensions |
|
| Diameter | Height | ||||||
| GNYG0.25 | KR15/30 | 2/3AA | 0.25 | 1.2 | 14 | 14.5 | 30.0 |
| GNYG0.27 | KR15/30 | 2/3AA | 0.27 | 1.2 | 16 | 14.5 | 30.0 |
| GNYG0.30 | KR15/30 | 2/3AA | 0.30 | 1.2 | 18 | 14.5 | 30.0 |
| GNYG0.5 | KR15/51 | AA | 0.5 | 1.2 | 25 | 14.5 | 50.5 |
| GNYG0.6-(2) | KR15/51 | AA | 0.6 | 1.2 | 26 | 14.5 | 50.5 |
| GNYG0.7 | KR15/51 | AA | 0.7 | 1.2 | 28 | 14.5 | 50.5 |
| GNYG0.7-(2) | KR15/51 | AA | 0.7 | 1.2 | 24 | 14.5 | 50.5 |
| GNYG0.8 | KR17/50 | A | 0.8 | 1.2 | 38 | 17.0 | 50.0 |
| GNYG1-(2) | KR17/43 | 4/5A | 1.0 | 1.2 | 38 | 17.0 | 43.0 |
| GNYG1 | KR17/50 | A | 1.0 | 1.2 | 40 | 17.0 | 50.0 |
| GNYG1-(3) | KR23/34 | 4/5SC | 1.0 | 1.2 | 45 | 23.0 | 33.0 |
| GNYG1.2 | KR23/43 | SC | 1.2 | 1.2 | 54 | 23.0 | 43.0 |
| GNYG1.3 | KR23/43 | SC | 1.3 | 1.2 | 55 | 23.0 | 43.0 |
| GNYG1.5 | KR23/43 | SC | 1.5 | 1.2 | 55 | 23.0 | 43.0 |
GNYG1.8-(3) |
5/4SC | 1.8 | 1.2 | 80 | 23.0 | 50.0 | |
| GNYG0.6 | 2/1C | 0.6 | 1.2 | 35 | 26.0 | 25.0 | |
| GNYG0.9 | KR26/25 | 2/1C | 0.9 | 1.2 | 35 | 26.0 | 25.0 |
| GNYG1.8 | KR26/50 | C | 1.8 | 1.2 | 80 | 26.0 | 50.0 |
| GNYG2.0 | KR26/50 | C | 2.0 | 1.2 | 95 | 26.0 | 50.0 |
| GNYG2.5 | KR33/44 | 2/3D | 2.5 | 1.2 | 110 | 33.0 | 44.0 |
| GNYG3 | KR33/62 | D | 3.0 | 1.2 | 140 | 33.0 | 61.5 |
| GNYG4 | KR33/62 | D | 4.0 | 1.2 | 165 | 33.0 | 61.5 |
| GNYG4.5 | KR33/62 | D | 4.5 | 1.2 | 165 | 33.0 | 61.5 |
| GNYG5 | KR33/62 | D | 5.0 | 1.2 | 180 | 33.0 | 61.5 |
| GNYG6-(2) | 6.0 | 1.2 | 200 | 33.0 | 67.5 | ||
| GNYG7 | KR33/91 | F | 7.0 | 1.2 | 260 | 33.0 | 91.0 |
| GNYG8 | KR33/91 | F | 8.0 | 1.2 | 260 | 33.0 | 91.0 |
| GNYG8-(2) | 8.0 | 1.2 | 250 | 33.0 | 85.0 | ||
| GNYG9 | KR33/91 | F | 9.0 | 1.2 | 260 | 33.0 | 91.0 |
| GNYG4-(2) | 4.0 | 1.2 | 170 | 37.5 | 49.0 | ||
| GNYG5-(2) | 5.0 | 1.2 | 190 | 37.5 | 49.0 | ||
| GNYG12 | 12 | 1.2 | 345 | 37.5 | 91.0 | ||
| GNYG6 | 2/3M | 6.0 | 1.2 | 250 | 43.5 | 61.0 | |
| GNYG7-(2) | 2/3M | 7.0 | 1.2 | 290 | 43.5 | 61.0 | |
| GNYG10-£¨2£© | KR44/91 | M | 10.0 | 1.2 | 420 | 43.5 | 91.0 |
| GNYG15 | KR44/91 | M | 15 | 1.2 | 43.5 | 91.0 | |
 |
 |
 |
 |
